#9104
Regular price $310.00
Taxes included.

The XD SIDE TWIST BRACKET is a universal solution designed to significantly reduce headroom above a roof rack fitted with an awning by 100mm once the awning is removed and the bracket is stowed. This universal bracket must be used with the RacksBrax quick release XD Hitch, which allows for quick and easy removal of the awning. Simply remove the awning in seconds with the XD Hitch, and to stow the bracket, unscrew the eyebolt, twist it 90 degrees from the vertical to the horizontal, reducing headroom to just 50mm, then screw in the eyebolt. No tools required—it’s that simple!

Key Features:

  • REDUCE HEADROOM above the roof rack from 150mm to 50mm in seconds
  • Unload accessory and twist the bracket sideways to stow in low headroom configuration, reversing to deploy
  • STOW and DEPLOY without the need for tools
  • Universal design that fits with the quick-release RacksBrax® XD Hitch (sold separately)
  • Made from 2-part stainless steel with black powder-coating for durability
  • Stainless steel fasteners included to suit most roof racks
  • Rated to 20kg (44lb) per bracket

Other Important Notes:

  • The LONG FOOT version is ideal for most universal platform-style roof racks with longitudinal slat configurations (without a perimeter lip).
  • For platform-style racks with a perimeter lip, bracket packers are required (not included).
  • For universal roof rack bars or platform-style racks with transverse slats, use the SHORT FOOT version.
  • Both SHORT FOOT and LONG FOOT versions are available in double and triple configurations.
  • Engineered and manufactured in Australia for superior quality and reliability.

This universal design ensures compatibility with a wide range of roof racks, offering easy stowing and deployment to maximize available headroom. Perfect for users who need a universal solution that is both functional and easy to use.

Sizes

HOW MANY BRACKETS FOR MY ACCESSORY?

Racksbrax XD Side Twist Brackets, both Short Foot and Long Foot, are sold in double
packs or triple packs.


The number of XD Side Twist Brackets must equal the number of XD Hitches recommended in the XD Hitch instructions.

HEADROOM

XD Side Twist brackets occupy 146mm of headroom above the top of the roof rack in the
deployed position reducing to 50mm with the bracket rotated into the stowed position
once the awning is removed.

DOOR CLEARANCE

XD Side Twist brackets occupy 42mm of clearance above the top of the roof rack in the deployed position and 82 mm with the bracket rotated into the stowed position once the awning is removed.
